Product Description:
ADC Pocket Otoscope & Ophthalmoscope Instrument: 5110N. ADC’s Pocket Instrument 5110N, is a full featured pocket otoscope and ophthalmoscope that sacrifice nothing but size. The Pocket Otoscope features: 2.5v halogen light source for true tissue color and long lasting lamp performance along with Fiberoptics for cool, obstruction free light transmission.
Additional 5110N Features: Wide angle, removable 2.5x viewing lens permits instrumentation and a sealed system with included insufflator fitting for pneumatic otoscopy. Otoscope head made from polymid – an impact resistant space age thermoplastic. Welch Allyn disposable polypropylene ear specula in 2.5 mm and 4.0 mm sizes are convenient, safe, and economical. “AA” metal battery handle interchanges with pocket Ophthalmoscope and pocket clip with integral on/off slide switch for ambidextrous use. Comes complete instrument includes insufflator fitting and tube of 5 each 2.5mm and 4.0mm specula and a Lifetime Quality Performance Guarantee on optics. The Pocket Ophthalmoscope features: 2.5v halogen light source for true tissue color and long lasting lamp performance with 5 aperture selections (small aperture, large aperture, fixation aperture, semicircle aperture, and red-free filter), 17 lenses from -20 to +20 diopters for better resolution. It has an Illuminated dial, Silicon coated protection of glass components, built-in lens dust cover, and the Rubber brow rest prevents scratching of eyeglasses. Ophthalmoscope head made from polymid – an impact resistant, space-age thermoplastic. Pocket clip with integral on/off slide switch for ambidextrous use. “AA” metal battery handle interchanges with pocket Otoscope comes with a Lifetime Quality Performance Guarantee on optics. See tabs for more information.
- Fiber optics for cool, obstruction-free light transmission
- 2.5v Xenon lamp for true tissue color
- Wide angle swivel 2.5x viewing lens permits instrumentation
- Insufflator port (fitting and insufflator sold separately) for pneumatic otoscopy
Ophthalmoscope features:
- 5 aperture selections (small spot, large spot, semicircle, fixed and red-free filter)
- 19 viewing lenses from -20 to +20 diopters for better resolution
- Illuminated magnified lens dial
- Rubber brow rest
- 2.5v Xenon lamp for true tissue color
Each instrument includes:
- “AA” battery handle (batteries included) with on/off power switch integrated into pocket clip
- Tube containing 5 each Welch Allyn 2.75mm and 4.25mm disposable specula
- 1 spare Xenon lamp for each instrument
- 2 “AA” batteries for each instrument
- 1 year instrument warranty, lifetime warranty on optics
Choice of hard or soft carry/storage case:
- Set in hard case measures 7 1/4″ x 4 1/2″ x 1 1/2″, weighs 1.07 lbs.
- Set in soft case measures 1 1/4″ x 7″ x 3 3/4″, weighs .67 lbs.
- 2.5v Xenon lamp for true tissue color
- 2.5x viewing lens
- Insufflator port (fitting and insufflator sold separately)
- 5 aperture selections (small spot, large spot, semicircle, fixed and red-free filters
- 19 viewing lenses from -20 to +20 diopters
- 2.5v Xenon lamp
- “AA” battery handle (batteries included) with on/off power switch integrated into pocket clip
- Hard case dimensions: 7 1/4″ x 4 1/2″ x 1 1/2″, weighs 1.07 lbs
- Soft case dimensions: 1 1/4″ x 7″ x 3 3/4″, weighs .67 lbs.
- 1 year instrument warranty, lifetime warranty on optics
- Battery Handle only: 5160N
- Ophthalmoscope Head only: 5140N
- Otoscope Head only: 5120N
- Lamp 2.5v for Ophthalmoscope: 5112N-4
- Lamp 2.5v for Otoscope: 5111N-4
- Storage Case: 925110N
- Disp. Specula (2.75 mm) 1000/pkg: 5182
- Disp. Specula (4.25 mm) 1000/pkg: 5185
- Insufflator Bulb Otoscope: 5122N
- Insufflator Fitting Otoscope: 5121N
