Product Description:
Medical Illumination System Two Halogen Series: S2D-20VC. The System MI System is an ideal combination of the System Two series of surgery lights and advanced video imaging. The result creates many possibilities to meet the changing needs of the surgery room. 8 input controller is available, sold separately.
S2D-20VC Features: Its flexibility of movement and central mounting at the same axis as the light allows for 300-degree rotation above the surgery table. The Video Camera provides excellent video imaging capabilities, at an incredibly low price. Additionally, as the camera is mounted on its own independent arm assembly, it can easily be ordered in combination with one or two Halogen Surgery Lights, creating a Duo or Trio system. Single camera controller is supplied. An optional 8 input controller is also available at extra cost.
Please Note: The Medical Illumination System Two Halogen Series Surgery Light has been discontinued. Please call for comparable item and/or if you have questions please contact Empire Medical Suppliers Pty Ltd, your authorized Medical Illumination dealer. See below for more information.
- Many possibilities to meet the changing needs of the surgery room
- Flexibility of movement and central mounting at the same axis as the light allows for 300-degree rotation above the surgery table
- The arm is compatible with most medical grade video monitors that have an S-Video input
- 102,000 lux (9,500 ft candles) output at 1 meter distance
- Over 4,000º Kelvin color temperature
- Fully adjustable light pattern
- Durable ceiling casting for optimum stability, balance and function
- 360º rotational contacts at all key points
- Electronic touch controls for on/off and dimming
- Removable sterilizable handle
- Reserve bulb with auto-switchover, in case of primary bulb failure
- Advanced suspension arm design, providing smooth extensive coverage
- Unique curved facial lens design
- 27x optical zoom
- Auto and manual focus
- Optional 8 video input controller (at additional cost)
- Sterilizable handle – standard
- Three (3) year manufacturer’s limited warranty*
*The limited warranty excludes all bulbs and LED’s
System Two 20″ Light & Video Camera:
- Weight: Approximately 104.5 lbs
- Dimensions: Ceiling Casting: 17.0″ diameter x 4.7″ deep
- Rotations – Ceiling Mount/extension arm interface: Continuous
- Articulating arm vertical movement: +20 – 70 degrees
- Articulating arm/Yoke interface: Continuous
- Yoke/lamp head interface: +/- 150 degrees
- Voltage: 100 – 125 VAC 50?60 Hz
- Lamp voltage: 23 – 25 VAC 50/60 Hz (150 Watts)
- Power: 120/230 VAC, 50/60 Hz 340 Watts
- Reflector: 20″ diameter polished aluminum, faceted
- IR/Color correcting filter glass: 4000º
- Irradiance: 314 W/m2
- Color Rendering Index: 90
- Focal length: 39″
- Central illuminance (adjustable): 2,000 -9,500 foot candles
- Maximum illuminance @ 33″: 10, 700 foot-candles
- Light field diameter (adjustable) 6.5″ – 9.0″
- Illuminance (one mask): 2,340 foot candles
- Illuminance (two masks): 3,300 foot candles
- Operating temperature: 41º – 104ºF
Medical Illumination System Two Halogen Brochure (click to view)
Available Options Sold Separately:
- Optional 8 Input Controller (shown below)
- Disposable Sterile Handle Covers – Carton of 160: BV-0001709
